Portable Photovoltaic Cleaning Robot
Six features of the product
One key to start rotation, intelligent path planning
One touch to start IFBOT intelligent robot. The unique cleaning mode with integrated sensors enables the robot to accurately detect the edge of the array and automatically adjust the angle to independently calculate the optimal and most efficient cleaning route, providing comprehensive coverage without missing out.
Adsorption dislocation working, adapting to various slopes
The IFBOT robot attaches itself tightly to the surface of the photovoltaic panel through movable suction cups, and the misplaced auxiliary cups enable it to walk more stably and freely on smooth slopes of 0-50℃, adapting to various complex working environments.
Lightweight and portable, zero burden on the panel
The innovative use of aerospace materials and the lightweight design of the whole machine avoid trampling damage to the panel during the cleaning process. The lightweight structure design reduces the user`s handling burden, and a single person can quickly deploy and manage dozens of machines at the same time, saving cleaning costs and effectively improving work efficiency.
Night cleaning, low battery automatic return
The IFBOT robot can safely carry out cleaning operations at night, and autonomously locate and return to the voyage when the battery is low. It does not affect the power generation of the power station during the day, and significantly improves the power generation efficiency of users.
The battery can be replaced, and the battery life is worry-free
A single robot is powered by 2 IFBOT dedicated lithium batteries, which can keep the whole machine running for 4 hours without interruption. The clip-type quick disassembly design can easily extend the battery life, and it only takes 1.5 hours to recharge.
Nano material, better cleaning without water
The single cleaning unit is equipped with two 2-way rotating nano-fiber roller brushes, which can gather the dust particles adsorbed on the surface after jumping up, and instantly suck the dust box through the centrifugal force of the turbocharged centrifugal fan. The same area does not need to be repeated, cleaning without water consumption, environmental protection and energy saving.
Technical Parameters
| Product name | Portable photovoltaic cleaning robot |
|---|---|
| Working method | Nano dry wipe and vacuum |
| Applicable scene | Photovoltaic power generation |
| Product Model | IFBOT X3 |
| Size | 1020*188*180mm |
| Net Weight | 6.2KG |
| Full battery life | 4H |
| Angle of adaptation | 0-45° |
| Cleaning efficiency | 300㎡/h (10 units for a group of continuous cleaning) |
Main machine
Battery
Charging stand
Charging stand+Battery
Efficient
Safe
Intelligent
Energy saving
Convenient
Economical
Case presentation
Mountain Power Station
Rooftop Distributed Power Station
Rooftop Distributed Power Station
Rooftop Distributed Power Station
Rooftop Distributed Power Station
